The bowl head hanging plate is a metal connector used in power transmission lines, mainly used to connect insulator strings with poles or wires. It is designed to withstand mechanical loads and ensure the stable operation of the power system.
Product Detail
Main features
High strength: Made of high-quality steel or alloy to ensure high mechanical strength.
Corrosion resistance: The surface is galvanized to extend the service life.
Flexibility: The design allows a certain angle of adjustment to meet different installation requirements.
Reliability: After rigorous testing, it ensures stable operation in harsh environments.
Application areas
Transmission lines: Connect insulator strings with poles or wires.
Substations: Used for equipment connection and support.
Railway electrification: Used for contact network systems.
Technical parameters
Material: High-strength steel, alloy
Surface treatment: Hot-dip galvanizing
Load capacity: Depending on the model, it is usually between a few tons and tens of tons
Product Parameters
 |  |  | ||||||
| W | WS | W | ||||||
| Type | Connection Marker | Main dimensions(mm) | Damage load (kN) | Weight (kg) | ||||
| B | C1 | C2 | Φ | H | ||||
| W-7A | 16 | 16 | 19.2 | 34.5 | 20 | 70 | 70 | 0.69 |
| W-7B | 16 | 16 | 19.2 | 34.5 | 20 | 115 | 70 | 0.86 |
| W1-10 | 16 | 18 | 19.2 | 34.5 | 20 | 85 | 100 | 0.9 |
| W1-12 | 16 | 20 | 19.2 | 34.5 | 24 | 90 | 120 | 1.3 |
| W-12 | 20 | 20 | 23 | 42.5 | 24 | 90 | 120 | 1.4 |
| W-30 | 24 | 32 | 27.5 | 51 | 39 | 110 | 300 | 3.5 |
| Type | Connection Marker | Main dimensions (mm) | Damage load Damage load(kN) | Weight (kg) | ||||
| C | C1 | C2 | M | H | ||||
| WS-7 | 16 | 18 | 19.2 | 34.5 | 16 | 70 | 70 | 0.97 |
| WS-10 | 16 | 20 | 19.2 | 34.5 | 18 | 85 | 100 | 1.7 |
| WS-12 | 20 | 24 | 23 | 42.5 | 22 | 90 | 120 | 3.81 |
| WS-12X | 16 | 24 | 19.2 | 34.5 | 22 | 90 | 120 | 3.1 |
| WS-12A | 16 | 20 | 19.2 | 34.5 | 22 | 85 | 120 | 1.8 |
| WS-16 | 20 | 26 | 23 | 42.5 | 24 | 95 | 160 | 2.64 |
| WS-20 | 24 | 30 | 27.5 | 51 | 27 | 100 | 200 | 4.3 |
Scene Graph
FAQ
Q
A
Can we print our trademark or company name on your product or package?
OEM and ODM orders are warmly welcomed, we have rich successful experience in OEM projects. In addition, our R&D team will provide you with professional suggestions.
Q
A
How does your company do in terms of quality control?
1) We choose all raw materials to be of high quality.
2) Professional and skilled workers pay attention to every detail in handling the production process.
3) The quality control department is specialized in quality inspection for each process.
Q
A
How can I get samples to test your quality?
We can provide free samples for you to test and check, just bear the freight cost.
Contact us to know more about our products, our professional team will serve you and customize it according to your requirements.
