The power fitting right-angle bracket is a metal component used for the installation and fixing of power lines. It is usually made of high-strength steel or aluminum alloy, and has the characteristics of corrosion resistance, wear resistance and high tensile strength. Its main function is to connect and support power equipment to ensure the stability and safety of the line.
Product Detail
Main features
1. High strength: able to withstand large mechanical loads.
2. Corrosion resistance: the surface is treated with anti-corrosion and suitable for outdoor environments.
3. Easy installation: reasonable design, easy to install and disassemble quickly.
4. High reliability: ensure the long-term stable operation of power lines.
Application scenarios
1. Transmission lines: used to connect and fix wires, insulators and other equipment.
2. Substations: used to support and fix busbars, cables, etc. in substations.
3. Distribution lines: used to connect and fix distribution equipment in distribution lines.
4. Overhead lines: used to connect and fix wires, insulators, etc. in overhead lines.
5. Special environment: suitable for harsh environments such as high altitude, strong wind, heavy ice, etc.
The right-angle bracket of power fittings plays a key role in the power system, ensuring the safety and stable operation of power lines, and is widely used in power transmission, substation, distribution and other scenarios.
Product Parameters
| ZBSRight angle bracket | |||||||
 |  | ||||||
| Type | Dimensions | (kN)Failure Load | (kg) Weight | ||||
| C | b | M1 | M2 | H | |||
| ZBS-16 | 26 | 60 | 24 | 24 | 63 | 160 | 4.80 |
| ZBS-20 | 26 | 60 | 24 | 24 | 100 | 200 | 5.08 |
| ZBS-25 | 30 | 60 | 27 | 27 | 120 | 250 | 6.65 |
| ZBS-32 | 38 | 60 | 36 | 36 | 136 | 320 | 7.40 |
| ZBS-32/16 | 26 | 60 | 36 | 24 | 140 | 160 | 6.80 |
| ZBS-32/21 | 30 | 60 | 36 | 27 | 140 | 210 | 7.20 |
| type | Dimensions | (KN)Failure Load | (kg) Weight | ||||
| C | b | M1 | M2 | H | |||
| ZBS-07/10-80 | 20 | 45 | 18 | 16 | 80 | 70 | 2.5 |
| ZBS-10/12-100 | 20 | 60 | 22 | 18 | 100 | 100 | 3.6 |
| ZBS-12/16-100 | 20 | 60 | 24 | 22 | 100 | 120 | 3.9 |
| ZBS-16/21-100 | 22 | 80 | 24 | 24 | 100 | 160 | 4.0 |
| ZBS-21/42-100 | 24 | 100 | 36 | 24 | 100 | 210 | 8.0 |
| ZBS-25/42-100 | 28 | 100 | 36 | 27 | 100 | 250 | 8.5 |
| ZBS-32/42-100 | 32 | 100 | 36 | 30 | 100 | 320 | 9.2 |
| ZBDRight angle bracket | |||||||
 |  | ||||||
| Type | (mm) | ||||||
| Catalog | Dimensions(mm) | Failure Load | Weight | ||||
| No. | C | H | ф | b | M | (≥kN) | (kg) |
| ZBD-07-80 | 20 | 80 | 18 | 16 | 16 | 70 | 0.9 |
| ZBD-07/10-80 | 20 | 80 | 18 | 16 | 18 | 70 | 1.1 |
| ZBD-07/12-80 | 20 | 80 | 18 | 16 | 22 | 70 | 1.3 |
| ZBD-07/21-90 | 24 | 90 | 18 | 16 | 24 | 70 | 2.2 |
| ZBD-10-80 | 20 | 80 | 20 | 16 | 18 | 100 | 1.1 |
| ZBD-10/12-80 | 20 | 80 | 20 | 16 | 22 | 100 | 1.3 |
| ZBD-10/16-90 | 22 | 90 | 20 | 16 | 24 | 100 | 2.2 |
| ZBD-10/21-90 | 24 | 90 | 20 | 16 | 24 | 100 | 2.5 |
| ZBD-12-90 | 20 | 90 | 24 | 16 | 22 | 120 | 1.5 |
| ZBD-12/25-110 | 28 | 110 | 24 | 16 | 27 | 120 | 3.5 |
| ZBD-16-90 | 22 | 90 | 26 | 18 | 24 | 160 | 2.5 |
| ZBD-16/21-90 | 24 | 90 | 26 | 18 | 24 | 160 | 2.6 |
| ZBD-16/32-120 | 32 | 120 | 26 | 18 | 30 | 160 | 4.4 |
